Magellan™ Safety Insulin Syringe with Needle, U-100, 1 mL, 29G x 1/2 Inch, Sterile, (CS/500EA)
Magellan™ Safety Insulin Syringe with permanently attached needle features a 1 mL U-100 insulin capacity, 29G x 1/2 inch stainless-steel needle, sliding safety shield, and low-dead-space design. Sterile, single use, and available 50/BX or 500/CS.
Customize
Product Details
Magellan™ Safety Insulin Syringe with Needle, U-100, 1 mL, 29G x 1/2 Inch, Sterile, BX/50EA & CS/500EA is designed for safe and accurate insulin administration in professional healthcare environments.
The syringe features a permanently attached stainless-steel needle to help reduce medication loss and dead space, along with clear, unobstructed U-100 graduations for dose visibility. Its integrated sliding safety shield offers full needle coverage after activation, while an audible and tactile click helps confirm that the safety mechanism has been engaged. Cardinal Health identifies the product as sterile, single use, individually packaged, and manufactured without DEHP or natural rubber latex.
Key Features
| Medication Delivery | Safety Design | Packaging |
|---|---|---|
| 1 mL / 100-unit insulin syringe | Sliding safety shield | 50 syringes per box |
| U-100 insulin graduations | One-handed activation | 10 boxes per case |
| 29G needle | 360° needle protection after activation | 500 syringes per case |
| 1/2 inch / 13 mm needle | Audible and tactile activation click | Individually packaged |
| Permanently attached needle | Low dead space | Sterile |
| Clear, bold graduations | Fixed needle tip | BX and CS selling units |
Cardinal's current product information describes one-handed activation, complete needle coverage, bold graduations, low dead space and an audible/tactile safety confirmation.
Specifications
| Attribute | Details | Attribute | Details |
|---|---|---|---|
| Brand | Magellan™ / Monoject™ Magellan™ | Manufacturer | Cardinal Health |
| MPN | 8881892910 | McKesson Item # | 661686 |
| Application | Safety Insulin Syringe with Needle | Volume | 1 mL / 100 Units |
| Insulin Type | U-100 | Graduations | U-100 Insulin |
| Needle Gauge | 29 Gauge | Needle Length | 1/2 Inch / 13 mm |
| Needle OD | Approx. 0.33 mm | Needle Material | Stainless Steel |
| Needle Style | Permanently Attached | Point Style | Regular Bevel |
| Tip Type | Fixed Needle Tip | Wall Type | Regular Wall |
| Safety Feature | Sliding Safety Needle Shield | Syringe Material | Polypropylene |
| Sterility | Sterile | Usage | Single Use |
| Packaging Type | Soft Pack | Rx Use | Yes |
| Natural Rubber Latex | Manufacturer states Not Manufactured With Natural Rubber Latex | DEHP | Manufacturer states Not Manufactured With DEHP |
| FDA Product Code | FMF – Syringe, Piston | GMDN | Insulin Syringe/Needle, Basic |
| Primary DI | 10192253025514 | Box DI | 20192253025511 |
| Case DI | 50192253025512 | HCPCS | A4206 |
| UNSPSC | 42142609 | BAA Compliant | No |
| TAA Compliant | Yes | Country of Origin | Not Verified |
| BX Packaging | 50 EA/BX | CS Packaging | 10 BX / 500 EA |
| Minimum Selling Units | BX; CS | EA Sales | No |
| Commercial Status | In Commercial Distribution | Lot Tracking | Yes |
| Expiration Date in UDI | Yes | Prescription Required | Yes – FDA GUDID |
McKesson verifies the gauge, length, U-100 graduations, safety mechanism, stainless-steel needle, polypropylene syringe, HCPCS A4206, UNSPSC 42142609, BAA/TAA status and sterile disposable configuration.
FDA's current record under Cardinal Health 200, LLC confirms MPN 8881892910, 29G × 1/2 inch, 1 mL capacity, sterile single-use Rx status and current commercial distribution.
Current FDA Device Identifiers
| Packaging Level | Quantity | Device Identifier |
|---|---|---|
| Individual Device | 1 EA | 10192253025514 |
| Box | 50 EA | 20192253025511 |
| Case | 10 BX / 500 EA | 50192253025512 |
FDA currently lists all three identifiers in commercial distribution.
FDA Record Transition Note
An older Cardinal Health GUDID identifier for this same MPN ended commercial distribution on December 31, 2025. A newer Cardinal Health 200, LLC record now lists the same MPN 8881892910 as In Commercial Distribution under Primary DI 10192253025514.
For MQ's current catalog, use the new active DI set shown above.
Warnings
| Clinical Use | Safety | Handling & Disposal |
|---|---|---|
| For U-100 insulin administration | Sterile single-use device | Dispose in approved sharps container |
| Verify prescribed dose before injection | Do not reuse | Activate safety shield immediately after use |
| For professional/Rx use as applicable | Do not use if sterile package is damaged | Confirm audible/tactile safety click |
| Confirm correct syringe capacity and insulin concentration | Do not attempt to remove permanently attached needle | Follow facility sharps policies |
| Follow applicable injection technique | Inspect device before use | Follow local regulations for disposal |
| Use only by appropriately trained personnel | Do not use beyond expiration date | Keep packaging intact until use. |
Specifications
- SterilitySterile
- Single PatientYes
- Autoclave ReadyNo
